Fulfilling the need for a compact RFID printing solution that can encode smart labels at the point of use, the R2844-Z printer/encoder is one of the most versatile in the industry! Designed for printing and encoding smart media such as wristbands and smart labels, the R2844-Z meets the needs of applications requiring greater processing speed and more connectivity choices-such as standard serial, parallel, and USB ports and optional internal Ethernet. It also offers the widest range of supported 13.56 MHz HF RFID transponders.

With a compact footprint, and processor that delivers faster print speed, it is the ideal solution for low-volume desktop applications, including express parcel delivery, library book/video check-out, sensitive document tracking, supply chain management (source tagging), ticketing (sports, concerts, etc.), and pharmaceuticals.

• Features
• Specifications

Specifications

PRINTER SPECIFICATIONS

Resolution 203 dpi (8 dots/mm)

Memory Standard: 8 MB SDRAM (4 MB available for user); 4 MB Flash (2.75 available to user) Optional: Up to 8 MB Flash with real time clock (12 MB total)

Print width 4.09″ (104 mm)

Print length 39″ (991 mm)

Print speed 2″ (51 mm)/sec 3″ (76 mm)/sec 4″ (102 mm)/sec

Media sensors Reflective Transmissive

MEDIA CHARACTERISTICS

Maximum label and liner width 4.25″ (108 mm)

Maximum label and liner length 39″ (990 mm)

Maximum roll diameter 5″ (127 mm) O.D. on a 1″ (25.4 mm) I.D. core

Core diameter 1″ (25.4 mm) to 1.5″ (38 mm); Using Media Adaptor Plates (included): 2″ (50.8 mm), 2.5″ (63.5 mm) and 3″ (76.2 mm)

Media thickness .003″/.08 mm to .0075″/.19 mm

Media types roll-fed, fanfold, die-cut, continuous, (black-mark optional), tag stock

RIBBON CHARACTERISTICS

Outside diameter 1.36″ (35 mm)

Standard length 244′ (74 mm) using .000328″ ribbon thickness

Ribbon width 1.30″ (33 mm) to 4.3″ (110 mm)

Ribbon setup Ribbon wound ink side out

ID Core 0.5″ (13 mm)

OPERATING CHARACTERISTICS

Operating temperature TT: Operating temperature 40° F (5° C) to 105° F (41° C) Thermal transfer DT: Operating temperature 40° F (5° C) to 105° F (41° C) Direct thermal

Storage temperatures -40° F (-40° C) to 140° F (60° C)

Operating humidity 10-90% non-condensing R.H.

Storage humidity 5-95% non-condensing R.H.

Electrical Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz

Agency approvals Emissions: FCC Part 15, Subpart C, C-Tick Emissions and Susceptibility: (CE): ETSI 300 330-2, ETSI EN301-489-3, EN55022 Class-B, EN61000-3-2, EN61000-3-3 and EN55024 Safety: CB Scheme IEC 60950: 1991 +A1 +A2 +A3 +A4, UL 60950 and C-UL

PHYSICAL CHARACTERISTICS

Width 7.9″ (201 mm)

Height 6.8″ (172 mm)

Depth 9.75″ (248 mm)

Weight 3.2 lbs (1.4 kg)

RELATED PRODUCTS

Options 8 MB Flash Memory w/ Real Time clock for a total of 12 MB (10.75 MB available to user) for applications Dispenser – Label peel and present with label taken sensor ZebraNet PrintServer II (internal and external) BAR-ONE Label Design Software

Communication and Interface Capabilities Centronics Parallel (36 Pin) connector ports RS-232 Serial Interface USB v 1.1 ZebraNet PrintServer II

PROGAMMING LANGUAGES

Core programming languages ZPL, ZPL II

BARCODES / SYMBOLOGIES

Linear Code 11 Code 39 Code 93 Code 128 Codabar UPC-A EAN-8 Plessey Interleaved 2-of-5 Standard 2-of-5 UPC-E EAN-13 Industrial 2-of-5 Logmars Postnet MSI Planet Code EAN-14 UPC-A and UPC-E with 2 or 5 digit extensions

2-dimensional Codablock MaxiCode PDF417 Data Matrix TLC 39 QR Code RSS / GS1 DataBar family (12 barcodes)

Fonts and Graphics Character Fonts: Standard bitmapped Zebra fonts: A, B, C, D, E (OCR-B), F, G, H, (OCR-A), GS, P, Q , R, S, T, U, V & Smooth font (CG Triumvirate Bold Condensed). Character Sets: IBM Code Page 850 International characters & graphic symbols Supports user defined fonts and graphics ? including custom logos Bitmap fonts are expandable up to 10 times, height and width independent. Fonts E and H (OCR-B and OCR-A), however, are not considered in spec when expanded. Smooth scalable font (CG Triumvirate Bold Condensed) is expandable dot-by-dot, height and width independent, while maintaining edges to a max. 1500 x 1500 dots. IBM Code Page 850 International Characters available in fonts A, B, D, E, F, G through software control.
